| Coaxial 4 Port Circulators |
| Wenteq Microwave Corporation
offers a wide range of narrow and wide bandwidth RF and microwave
isolator and circulator products in coaxial, drop-in and waveguide
configurations. These products cover the frequency range from 40MHz to
100GHz. Customers can select from the products listed below or simply
send us your application requirements and we will pick the best match
from our product list or specifically design it to meet customer
requirements.
|
|
|
| |
| Type |
Freq.
(GHz) |
BW
(MHz) |
S-J
Ins.(dB) |
D-J
Ins.(dB) |
S-J
Iso.(dB) |
D-J
Iso.(dB) |
VSWR |
Temp.
(C) |
Forward
CW Power
(W) |
Con-
nector |
Dimension
LxWxH
(mm) |
| F2915 |
0.07-0.25 |
22% |
0.6 |
1.2 |
20 |
40 |
1.2 |
-25-+50 |
100 |
N,SMA |
5.5X2.76X1.26 |
| F2916 |
0.08-0.25 |
22% |
0.6 |
1.2 |
20 |
40 |
1.2 |
-10-+60 |
50 |
N, SMA |
5.5X2.76X1.25 |
| F2917 |
0.9-1.8 |
24% |
0.5 |
1.0 |
20 |
40 |
1.2 |
-30-+60 |
50 |
SMA |
(70X35X22) |
| F2928 |
1.9-2.5 |
10 |
0.5 |
0.8 |
20 |
40 |
1.2 |
-40-+70 |
10 |
N, SMA |
(70x35x20) |
| F2932 |
1.7-3.0 |
400 |
0.5 |
1.0 |
20 |
40 |
1.2 |
-40-+70 |
30 |
SMA, N |
(64X35X20) |
| F2936 |
2.8-4.0 |
500 |
0.5 |
1.0 |
20 |
40 |
1.2 |
-30-+60 |
200 |
DIN7/16, N |
(120X60X30 |
| F2942 |
0.4-0.8 |
90 |
0.5 |
1.0 |
20 |
40 |
1.2 |
-30-+60 |
50 |
SMA, N |
3.8X2X1.0 |
| F2948 |
0.4-0.97 |
300 |
0.5 |
1.0 |
20 |
40 |
1.2 |
-40-+70 |
50 |
SMA, N |
(120X60X30) |
|
|
